SD90VU VHF/UHF Mobile Mag-Mount Antenna

The SD90VU is a high-performance dual band VHF/UHF mobile antenna designed for 144/430MHz. With 2.5/3.5dBi gain, ≤1.5 VSWR, and 50Ω impedance, it delivers stable omni-directional communication for vehicle-mounted radio systems.

Featuring a magnetic base (recommended 90mm diameter) and SMA connector options, this antenna is ideal for amateur radio, handheld and mobile transceivers.

---

SD90VU VHF/UHF Mobile Antenna Specifications:

Model No. SD90VU
Type Combination Antenna
Place of Origin China
Frequency Range 144/430MHZ
Gain 2.5/3.5dBi
Connector SMA-male
V.S.W.R Less than 1.5
Impedance 50ohm
Length VU:490mm
